BUSSMANN S504玻璃管保险丝 5*20 慢断保险丝
参数表
| 料号 | 额定电压 | 分断能力 | 冷电阻 | 熔断能量值 |
| S504-32-R | 250V | 35A | 21.7 | 0.0014 |
| S504-40-R | 250V | 35A | 14.2 | 0.0034 |
| S504-50-R | 250V | 35A | 9.5 | 0.006 |
| S504-63-R | 250V | 35A | 7.1 | 0.012 |
| S504-80-R | 250V | 35A | 4.5 | 0.015 |
| S504-100-R | 250V | 35A | 2.8 | 0.022 |
| S504-125-R | 250V | 35A | 2.0 | 0.034 |
| S504-160-R | 250V | 35A | 1.3 | 0.052 |
| S504-200-R | 250V | 35A | 1.0 | 0.078 |
| S504-250-R | 250V | 35A | 0.66 | 0.17 |
| S504-315-R | 250V | 35A | 0.46 | 0.41 |
| S504-400-R | 250V | 35A | 0.37 | 0.61 |
| S504-500-R | 250V | 35A | 0.27 | 0.75 |
| S504-630-R | 250V | 35A | 0.19 | 1.3 |
| S504-800-R | 250V | 35A | 0.13 | 3.1 |
| S504-1-R | 250V | 35A | 0.064 | 3.6 |
| S504-1.25-R | 250V | 35A | 0.046 | 7 |
| S504-1.6-R | 250V | 35A | 0.039 | 10 |
| S504-2-R | 250V | 35A | 0.029 | 17 |
| S504-2.5-R | 250V | 35A | 0.024 | 34 |
| S504-3.15-R | 250V | 35A | 0.018 | 56 |
| S504-4-R | 250V | 35A | 0.013 | 91 |
| S504-5-R | 250V | 35A | 0.0095 | 133 |
| S504-6.3-R | 250V | 35A | 0.0085 | 270 |
